SKU: XP23HPE

Condition: New

$999.00 + Free Shipping
/

Estimate Only, Carrier Delays May Occur
Shipping to
|
Change
Ship To

1-3 DAY DELIVERY!!!

Shipping from 2 locations to serve you better. CA. and TN.

We offer FREE ground shipping on all orders OVER $199 ( 48 Contiguous States Only) All other orders under $199 will have a $8.95 flat rate ground shipping. Express Shipping is based on your order's weight and your shipping address. All other locations outside of the Continental US will receive discounted rates

XP23HPE manual cover Product Manual
XP23HPE Warranty Warranty
Features
  • 713cc 4 Stroke OHV engine
  • Runs on Standard 87 Octane Gasoline
  • Electric Start Key Switch Box
  • Air Cleaner: Dual, Semi-dry, Oil Bath
  • EPA and CARB Approved for Safe Mandated Use
  • Applications: Go Karts, Pressure Washers, Trailer Mounted - Mobile Carwashes, Log Splitters, RotoTillers - Cultivators, Water/Trash Transfer Pump
What's in The Box
  • DuroMax XP23HPE Engine
  • Owners Manual
Warranty
  • 3-Year Limited Factory Warranty
  • 30 Day Satisfaction Guaranteed
Specifications
Brand DuroMax Power Equipment
SKU XP23HPE
Engine Type 4-Stroke
Valve Type OHV
Engine Cooling Type Forced Air
Displacement 713cc
Bore 80mm
Stroke 71mm
Compression Ratio 8.5:1
Max Output 4000 RPM
Max Torque 31.72 ft-lbs (43 N.m.)@ 2500RPM
Shaft Orientation Horizontal
Shaft Size 1" Diameter, 3.01" Long, 1/4" x 2" Keyway
Shaft End 3/8" Size 24 UNF - 2B
Shaft Rotation Counter Clockwise
Measurement from Center of Shaft to Base 5.29"
Fuel Types Gasoline
Fuel Delivery System Carburetor
Starting Type Key Switch
Electric Start Yes
Cast Iron Sleeve Yes
Bearing Type Stainless Steel Needle Bearings
Oil Cooling Type Pressure and Splash
Oil Capacity 54.1 fluid oz.
Recommended Oil 10W-30
Recommended Oil Types Blended, Conventional, or Synthetic
Product Dimensions 19.3"-Long x 18.3"-Wide x 14"-High
Product Weight 103.6-lbs
UPC 811640016067
Warranty 3 Year
EPA Certified Yes
CARB Certified Yes
50 State Emissions Yes
Package Dimensions 21.5"L x 21.1"W x 19.1"H
